PE Foam Tape

PE foam tape stands for polyethylene foam tape. Closed cell polyethylene foam products are formed by chemical crosslinking, from low to high magnification. And the foaming rate varies from 3 to 50 times. Plus, the foam hole of the product is uniform and delicate, soft to the touch, and can be made into a variety of colors, a wide range of applications. Moreover, all products meet the RoHS environmental requirements. PE foam tape adopts PE foam as base material, coated with aggressive high bond pressure sensitive glue. And then protected by yellow kraft liner. Furthermore, we can either provide jumbo rolls, or die cutting pieces. The width can be from 10mm to 1600mm, the length can be from 100mm to 2000mm. Last but not least, it is widely used in home appliance industries, automotives, electronics industries, etc.


egret

PE Foam Tape Specifications

Product CharacteristicsPerformance DataTest Method
Carrier ColorWhiteVisual
Liner ColorYellowVisual
Density≥40 KG/m³ASTM D-3575
Peel Adhesion≥6 N/CMASTM D-3330
Loop Tack17 # steel ballGB/T 4852-84
Tensile strength15 N/CMASTM D3759
Elongation≥150%ASTM D-3330
Temp Resistance-30℃~80℃


Features of PE Foam Tape

Features of PE Foam Tape

  • 1mm high-density closed-cell PE foam as carrier

  • Coated with special formula of very high tack adhesive

  • Laminated with yellow kraft paper easy release liner

  • Excellent properties of sound dampening, cushioning

  • Touch feeling like wax, odorless, non-toxic

  • Good low temperature resistance

  • Stable chemical properties, good corrosion resistance

  • Outstanding conformity to uneven surfaces

Process of PE Foam Tape Production

Process of PE Foam Tape Production
Process of PE Foam Tape Production
NO.1

First, closed cell polyethylene foam products are formed by chemical crosslinking, from low to high magnification. And the foaming rate varies from 3 to 50 times.


NO.2

Second, we coat single sided or double-sided high adhesion of pressure sensitive glue.


NO.3

hird we laminate the kraft silicon paper liner or PET liner on which.


NO.4

Finally, we use our lathe slitting machines to cut the jumbo rolls to different standard or non-standard width and length of small rolls. Meanwhile, we can also cut them to different shapes of die cutting pieces.


FAQ of PE Foam Tape

FAQ of PE Foam Tape

What is PE foam tape?

PE foam tape is made of polyethylene base material and adhesive, with paper liner.


01

What is the characteristic of PE foam?

It is odorless, nontoxic, touch like wax, stable chemical properties.


02

What type of glue do you use?

Aggressive pressure sensitive acrylic adhesive.


03

What is PE foam tape used for?

Sealing, thermal insulation, acoustic insulation of roofs, etc


04
